Sand-vik DD/DL with joystick85336089

1
MOQ
1180
Price
Sand-vik DD/DL with joystick85336089
Features Gallery Product Description Chat Now
Features
Specifications
Maximum Speed: 4 M/s
Condition: High Quality
Axial Thrust N: 115
Ambient Temperature: -15~40 °C
Grade: Q235,SM490,SS400,Q235...
Each Time Number: 1-2
Safety Features: Emergency Stop, Overload Protection, Operator Cabin Protection
Coupler Type: Scharfenberg 35
Function: Excavation, Drilling, Crushing, And Material Handling
Plastering Width: 830 Mm
Wheelbase Wheelbase: 3000mm
Operating Temperature Range: -20°C To 50°C
Engine Model: 490
Tar T: 30
Working Stroke: 1450
Basic Infomation
Place of Origin: CHINA
Brand Name: Sand-vik
Model Number: 85336089
Payment & Shipping Terms
Packaging Details: Original packaging
Delivery Time: 15days
Payment Terms: T/T
Supply Ability: 9999
Product Description

Sand-vik 85336089 (Joystick for DD/DL Series)


1. General Description


Part number 85336089 is an original Sand-vik 24V electronic joystick. It is mainly applied to Sand-vik DD development drill rigs, DL longhole drill rigs and some LH underground loaders, delivering precise control over boom movement, feed, rotation, travelling and other operations.

2. Main Specifications


  • Part No.: 85336089 (Genuine Sand-vik)
  • Type: Electronic proportional joystick (2-axis / 3-axis)
  • Working Voltage: 24V DC
  • Compatible Models:
    • DD Series: DD210, DD322i, DD422i, DD422iE
    • DL Series: DL311, DL422i, DL422iE
    • Other Equipment: LH series loaders, selected surface drill rigs

  • Functions: Control boom lifting, extending and slewing, feeder feed rate, rotational speed, travelling steering, etc.

3. Appearance Features


  • Base: Black engineering plastic body with rubber dust boot
  • Grip: Anti-slip rubber handle on the top, equipped with 1 to 2 function buttons (e.g. rapid feed, emergency stop)
  • Mounting & Connection: 4-hole mounting at the bottom; equipped with CANbus or 0–5V signal output port

4. Differences from Hydraulic Lock & Check Valve


  • 85336089 (Joystick): Control unit. It sends signals to solenoid valves to adjust hydraulic flow direction.
  • 8231120286 (Cartridge Check Valve): Maintains pressure and prevents fluid backflow in hydraulic circuits.
  • 9106063010 (Hydraulic Lock / Pilot-operated Double Check Valve): Locks cylinders firmly in position to avoid position drifting.

5. Replacement & Interchangeability


  • Genuine Sand-vik Alternative: 85577689 (Upgraded version, fully compatible in functions)
  • Domestic Replacement: Standard 24V electronic joystick with identical specifications (Epiroc equivalent parts are also applicable)
