TCG2032、CG260 MWM / Deutz Camshaft Bearing Pair 12280131

1
MOQ
5039
Price
TCG2032、CG260 MWM / Deutz Camshaft Bearing Pair 12280131
Features Gallery Product Description Chat Now
Features
Specifications
Structure Material: Bimetallic Steel Backing + Lead-tin Anti-friction Alloy Lining
Surface Process: Precision Boring, Custom Oil Grooves For Oil Storage And Lubrication
Wear Resistance: Resist High-speed Friction And Engine Oil Corrosion, Stable Under Full-load Continuous Operation
Continuous Operating Temperature: -30℃ ~ 180℃
Matching Rated Speed: 1500rpm / 1800rpm Standard Generator Speed
Service Life Standard: Up To 80,000 Working Hours Without Journal Scoring Or Abnormal Noise
Net Weight Per Set: 0.75 Kg / 1.65 Lbs
Outer Package Size (per Set): 160×85×35 Mm
Net Weight (per Set): 0.75 KG
Gross Weight (per Set): 0.82 KG
Standard Export Carton (50 Sets/carton): 420×300×220 Mm
Full Carton Gross Weight: 43 KG
Basic Infomation
Place of Origin: Germany
Brand Name: MWM
Model Number: 12280131
Payment & Shipping Terms
Packaging Details: Original packaging
Delivery Time: 15days
Payment Terms: T/T
Supply Ability: 9999
Product Description

1. Basic Part Information

  1. OEM Part No.: 12280131
  2. Product Name: Camshaft Bearing Pair
  3. Compatible Engines: Deutz MWM TCG2032, CG260 series diesel & gas engines
  4. Application Equipment: Stationary gas generator sets, diesel power stations, industrial backup power units
  5. Mounting Position: Camshaft support positions on engine cylinder block
  6. Matching Overhaul Parts: Main Bearing 12282842, Thrust Washer 12283463

2. Material & Performance Specifications

Parameter Item Technical Specification
Structure Material Bimetallic steel backing + lead-tin anti-friction alloy lining
Surface Process Precision boring, custom oil grooves for oil storage and lubrication
Wear Resistance Resist high-speed friction and engine oil corrosion, stable under full-load continuous operation
Continuous Operating Temperature -30℃ ~ 180℃
Matching Rated Speed 1500rpm / 1800rpm standard generator speed
Service Life Standard Up to 80,000 working hours without journal scoring or abnormal noise
Net Weight Per Set 0.75 kg / 1.65 lbs

3. Physical & Packaging Specifications


Parameter Item Metric Standard Imperial Standard
Outer Package Size (per set) 160×85×35 mm 6.3×3.3×1.4 inch
Net Weight (per set) 0.75 KG 1.65 lbs
Gross Weight (per set) 0.82 KG 1.81 lbs
Standard Export Carton (50 sets/carton) 420×300×220 mm 16.5×11.8×8.7 inch
Full Carton Gross Weight 43 KG 94.8 lbs

4. Product Features

This 12280131 camshaft bearing is supplied as a matched pair. Specially designed oil grooves on the inner surface maintain complete oil film during high-speed camshaft rotation, preventing metal-to-metal dry friction and camshaft journal damage.

Full replacement of this bearing set is mandatory during engine overhaul or camshaft maintenance, which effectively eliminates engine idle knocking noise and abnormal engine oil pressure.

5. Warranty

12 months warranty with unlimited running hours under normal operating conditions.
